Name: 50-60T Tipper Semi Trailer 3 Axles Blue
Brand: CHINA NATIONAL HEAVY DUTY INDUSTRY GROUP LIMITED
SKU: LML9400GYY
Availability: InStock

Detalhes do produto

Lugar de origem: China

Marca: SINOTERCEL

Certificação: ISO/3C/SGS/BV

Número do modelo: LML9400GYY

Termos de pagamento e envio

Quantidade de ordem mínima: 1 unidade

Preço: Negociável

Detalhes da embalagem: depilação

Tempo de entrega: 25 DIAS ÚTEIS

Termos de pagamento: T/T

Habilidade da fonte: 1000 unidades/mês

Obtenha o melhor preço

Detalhes do produto

Descrição do produto

Destacar:
                                                                                                                                                                                    50-60T tipper semi trailer, 3 axles tipper semi trailer, blue tipper semi trailer


Hidráulico:	sistema hidráulico	Grossura:	Parede lateral: 8 mm; Piso inferior: 10 mm
Comprimento total:	7500 mm	Kingpin.:	JOST Bolt em King Pin
Recurso:	Serviço Pesado	Placa inferior:	8mm

Hidráulico:	sistema hidráulico
Grossura:	Parede lateral: 8 mm; Piso inferior: 10 mm
Comprimento total:	7500 mm
Kingpin.:	JOST Bolt em King Pin
Recurso:	Serviço Pesado
Placa inferior:	8mm

50-60T Tipper Semi Trailer 3 Axles Blue

50-60T Tipper Semi Trailer 3 Axles Semi Flatbed Trailers Blue

Product Description:

Product features of low flat transport semi-trailer:
The load-carrying surface of the cargo platform of the frame is low, which is suitable for the transportation of various construction machinery and large-scale equipment. It is widely used, efficient and fast.
Reasonable structure: The whole vehicle is optimized by advanced computer-aided design system, and the frame adopts a frame structure combining penetrating beams and I-shaped beams, which has high strength, good rigidity and toughness.
Advanced technology: The longitudinal beam is made of low-alloy steel specially used for automobiles and welded by a fully automatic buried welding machine. The parts of the frame are all shot blasted to enhance the paint adhesion and weather resistance, making the vehicle beautiful and practical.
Suspension system: The tandem independent balance suspension system is adopted to ensure the load balance of each axle.

Parameter:

Heavy Equipment Semi Trailer Storage Boxes , Hydraulic Semi Flatbed Trailers
Model	3 Axles 60Tons
Axle	FUWA brand, 16ton, 3 Sets
Cargo Body	1050023001500mm, floor:10mm, side:6mm
Material	Carbon steel or Mn steel
Gross vehicle weight	75000kgs
King pin	#90
Support leg	JOST Standard 28T
Suspension	Normal suspension
Thickness leaf spring	10/10/10
Tire/Rim	1200R20, 13pcs, 8.5, 12 pcs
Brake Chamber	Standard 6 pcs
Spare wheel carrier	2 pcs
Tool box	1 pcs
Electrical System	Chinese standard 24C lighting system
Side Maker Lamp	LED lamp
Painting	Polyurethane Paint
Overall dimension	12000×2500×3880(mm)
Color	White, red, green, golden and so on.
Heavy Equipment Semi Trailer Storage Boxes , Hydraulic Semi Flatbed Trailers
